Navigate Without BuildContext in Flutter using a Navigation Service

In this tutorial we will go over the process of implementing a navigation service that will allow you to navigate without the BuildContext. The only time this will be applicable is if you have separated your UI code from your business logic, similar to this architecture. By having the navigation in the service you can navigate at the same place where you're making your actual business logic decisions and don't have to direct back to your UI code where the context is available. This is the same reason you would want to build yourself a Dialog Manager like this where you can show and get input from dialogs right where your business logic requires it.

This is another step in the direction of making sure your view file only shows UI and the rest is managed somewhere else.

The idea we'll use to achieve this is the following. Have a service that contains a GlobalKey of type NavigatorState. Expose a function to push a named route and pass in optional arguments if required. I ALWAYS say services should never be used from within a view file, and that's still true, but by the word use I mean calling functions that change state or perform business logic. All we're doing here is setting a value that is required by the state to make sure we can link our service to the UI.

I have setup a basic app using to the provider-get_it architecture that has the navigation in the UI so that I can also cover why you'd want to move the functionality into your model. Download the code and open up the project in your IDE of choice.

The code in the project has two views with their viewmodels associated with it. Login and Home. Both have a button on screen, on Login is a login button and on Home is a logout button. The views will call a function on the model to perform some kind of business logic and then return to the UI to perform a conditional navigation. That's what we want to avoid. We want ALL logic in the model, that includes checking if something is a success and performing a navigation depending on the outcome.

If you go to the Home view you'll see the following code in the onTap function for the GestureDetector.

 onTap: () async {
    var success = await model.login(success: true);
    if (success) {
      Navigator.of(context).pushNamed(routes.HomeRoute);
    }
  },

This is typically how you would navigate, mostly because you don't have the BuildContext available in your model. As you can see from this code there's logic relating to the functionality. This means that as the application features expand we are likely to add more logic in here. That's something we definitely want to avoid doing when working in a view file that's "supposed" to be UI only. The model should handle all logic, the view should only call functions on the model and then rebuild itself using the new state when required.

To adhere to that principle we'll move the Navigation functionality into a service that we can call from the model classes. Create a new folder under lib called services and in there create a new file called navigation_service.dart

class NavigationService {
  final GlobalKey<NavigatorState> navigatorKey =
      new GlobalKey<NavigatorState>();

  Future<dynamic> navigateTo(String routeName) {
    return navigatorKey.currentState.pushNamed(routeName);
  }

  bool goBack() {
    return navigatorKey.currentState.pop();
  }
}

Open up the locator.dart file and register the navigation service

GetIt locator = GetIt.instance;

void setupLocator() {
  locator.registerLazySingleton(() => NavigationService());
}

The way we link our NavigationService with the application is be supplying the key from the service to the MaterialApp. Go to the main.dart file and set your navigatorKey.

class MyApp extends StatelessWidget {
  // This widget is the root of your application.

  Widget build(BuildContext context) {
    return MaterialApp(
      ...
      navigatorKey: locator<NavigationService>().navigatorKey,
      onGenerateRoute: router.generateRoute,
      initialRoute: routes.LoginRoute,
    );
  }
}

Now that the service is setup and implemented we can go places it's being used and move that logic into the viewmodel. Head over to the LoginView and update the onTap function for the GestureDetector to remove all the login an await functionality.

 GestureDetector(
    onTap: () {
      model.login(success: true);
    },
    child: ...
  )

Open the LoginViewModel and import the route_paths file as routes. Then we'll retrieve the NavigationService as a private final field and when success we will call the navigation service to navigate to the HomeRoute.

import 'package:nav_service/constants/route_paths.dart' as routes;
import 'package:nav_service/services/navigation_service.dart';
...

class LoginViewModel extends BaseModel {

  final NavigationService _navigationService = locator<NavigationService>();

  Future login({bool success = true}) async {
    setBusy(true);
    await Future.delayed(Duration(seconds: 1));

    if (!success) {
      setErrorMessage('Error has occured with the login');
    } else {
      _navigationService.navigateTo(routes.HomeRoute);
      setErrorMessage(null);
    }

    setBusy(false);
  }
}

That's it. Now the responsibility of the View file is taken back to Showing UI and passing user actions to the model, instead of Showing UI, passing user actions to model and navigating. The HomeView is exactly the same as LoginView so all we'll do is update the onTap function and remove the conditional back navigation.

GestureDetector(
  onTap: () {
    model.logout();
  },
  child: ...
)

Then we update the HomeViewModel to perform the back navigation through the NavigationService.

import 'package:nav_service/services/navigation_service.dart';

class HomeViewModel extends BaseModel {
  final NavigationService _navigationService = locator<NavigationService>();

  Future logout({bool success = true}) async {
    setBusy(true);
    await Future.delayed(Duration(seconds: 1));

    if (!success) {
      setErrorMessage('Error has occured during sign out');
    } else {
      _navigationService.goBack();
    }
  }
}

The benefits of this is as the navigation logic expands your UI will stay the same and the model will carry all the logic / state management. This coupled with the Dialog Manager tutorial should get all your "Widget showing" functionality out of your views and into your business logic where they belong.

Having navigation arguments is a common task so we'll add it into the navigation service. If you want a more in depth walk through of the Navigation in Flutter look at this tutorial.

We'll start by adding an optional dynamic parameter to the navigateTo function in the NavigationService and passing that to our pushNamed call.

Future<dynamic> navigateTo(String routeName, {dynamic arguments}) {
  return navigatorKey.currentState.pushNamed(routeName, arguments: arguments);
}

Now in the LoginViewModel where we navigate we'll pass in a argument of type String to show in the HomeView on the Button.

_navigationService.navigateTo(routes.HomeRoute, arguments: '\nFilledStacks');

Now head over to the router.dart and under the HomeRoute case we'll extract the arguments from the settings and pass it to the HomeView.

...
  case routes.HomeRoute:
    var userName = settings.arguments as String;
    return MaterialPageRoute(
        builder: (context) => HomeView(userName: userName));
...

Then lastly. In the HomeView we can add the userName parameter to the constructor and set that to the field userName. To show the username we'll append it to the 'Logout' text.

class HomeView extends StatelessWidget {
  final String userName;
  const HomeView({Key key, this.userName}) : super(key: key);


  Widget build(BuildContext context) {
    return ChangeNotifierProvider(
      ...
      Text('Logout' + userName,
      style: TextStyle(
          fontWeight: FontWeight.w800,
          color: Colors.white,
          fontSize: 30))
    );
  }
}

And that's all you need. Now you can go ahead and move all your navigation into your models, out of your views and keep all your business logic together.
