A Responsive UI Architecture Solution with Provider

This is the final tutorial for creating a production level Responsive UI architecture. Part 1 covered the process of building a base widget that provides us with all the important information. Part 2 makes use of the BaseWidget information and builds the UI widgets required to provide layouts for different screen sizes as well as different orientations. This tutorial is the step where we add State Management to the Architecture to complete our architecture. For state management we'll use Provider as always to provide us with our UI State Management needs.

To follow along with this tutorial you can download the starting code from here or use the code you created from part 2.

If you're like me and can discern an implementation just from source code here's the final result. Then also, I have separate tutorials for my complete Provider Architecture so I won't go over it in detail or add any business logic.

There are a few things we'd like to achieve with the state management solution for this architecture. The first thing is to keep the responsive UI friendly setup but avoid repeating code, specifically for passing data or a viewmodel to ALL the different layouts one responsive widget might have, 6 in total. Secondly I want the ease of my traditional Provider architecture in terms of the onModelReady call as well as the UI rebuilding when a ViewModel's state has changed. Aaaaand I think I have come up with a pretty solid implementation.

Before we start with the code we have to add Provider to the project. Go to the pubspec file and add provider

provider:

Then we can cover the traditional Provider setup. We'll create a BaseWidget with a minor adjustment. Instead of using a Consumer as the child of the ChangeNotifierProvider we'll execute the builder function and pass the resulting widget to the child property. Everything else will stay the same as the original setup. Create a new file under the widgets folder called base_widget.dart.

class BaseWidget<T extends ChangeNotifier> extends StatefulWidget {
  final Widget Function(BuildContext) builder;
  final Function(T) onModelReady;
  final T viewModel;

  BaseWidget({
    Key key,
    this.builder,
    this.onModelReady,
    this.viewModel,
  }) : super(key: key);


  _BaseWidgetState<T> createState() => _BaseWidgetState<T>();
}

class _BaseWidgetState<T extends ChangeNotifier> extends State<BaseWidget<T>> {
  T _model;


  void initState() {
    super.initState();
    _model = widget.viewModel;

    if (widget.onModelReady != null) {
      widget.onModelReady(_model);
    }
  }


  Widget build(BuildContext context) {
    return ChangeNotifierProvider(
      builder: (context) => _model,
      child: widget.builder(context),
    );
  }
}

This will handle passing the ViewModel down to the resulting UI and giving us the onModelReady callback for initialisation before the UI is rendered. Now, with the responsive architecture as shown in Part 2 we create completely separate widgets for each of the combinations of DeviceScreenType and Orientation. This means that if we have a viewmodel or plain data model that we want to access in all of these views, we would like to not have to call Provider.of<Model>(context) in every view. That's the second Base file we'll build.

What we'll build is a BaseModelWidget that returns to us our view model or data model in the build method 😎😍😎😍😎😍 I'm so excited about that haha. You'll see what difference this makes, I'm actually thinking of using it in my traditional non responsive architecture as well. We'll talk about that in a later tutorial. In the widgets folder create a new file called base_model_widget.dart. It will extend the Widget class and and make use of a custom element that calls Provider.of<Model>(context) for us.

abstract class BaseModelWidget<T> extends Widget {

  // Define that we want to get back a type of T when building
  // Make it abstract so that we have to override, like a stateless or stateful widget.

  Widget build(BuildContext context, T model);


  _DataProviderElement<T> createElement() => _DataProviderElement<T>(this);
}

class _DataProviderElement<T> extends ComponentElement {
  _DataProviderElement(BaseModelWidget widget) : super(widget);


  BaseModelWidget get widget => super.widget;

  // When executing the above build method, we pass back the model we get from Provider.

  Widget build() => widget.build(this, Provider.of<T>(this));
}

The comments explain what I'm going to type here. We created an abstract class with one method to implement. The build method. This build method will provide us with the BuildContext as well as the type T or Model to be more specific. The _DataProviderElement will request the type passed in from provider by doing the Provider.of call for us. That's all the architectural parts setup, now we can go ahead and use this functionality.

The first thing I'd like to apply it to is the way we pass down information to the drawer option layouts. We'll start by creating a data model to represent the drawer option. Create a new folder called datamodels and under it a new file called drawer_item_data.dart.

class DrawerItemData {
  final String title;
  final IconData iconData;

  DrawerItemData({
    this.title,
    this.iconData,
  });
}

Then we can head over to the drawer_option.dart file. We'll remove all the data passing down to the layout files and instead surround the ScreenTypeLayout with a Provider.value widget that takes in a new DrawerItemData constructed with the passed in properties to the DrawerOption widget.

class DrawerOption extends StatelessWidget {
  final String title;
  final IconData iconData;
  const DrawerOption({
    Key key,
    this.title,
    this.iconData,
  }) : super(key: key);


  Widget build(BuildContext context) {
    return Provider.value(
      value: DrawerItemData(title: title, iconData: iconData),
      child: ScreenTypeLayout(
        mobile: OrientationLayout(
          landscape: (context) => DrawerOptionMobileLandscape(),
          portrait: (context) => DrawerOptionMobilePortrait(),
        ),
        tablet: OrientationLayout(
          portrait: (context) => DrawerOptionTabletPortrait(),
          landscape: (context) => DrawerOptionMobilePortrait(),
        ),
      ),
    );
  }
}

As you can see the OrientationLayout has some errors and that's because I had to change the implementation because of some weird widget state that came up when swapping orientations with the drawer open. The new OrientationLayout looks like this.

class OrientationLayout extends StatelessWidget {
  final Widget Function(BuildContext) landscape;
  final Widget Function(BuildContext) portrait;
  const OrientationLayout({
    Key key,
    this.landscape,
    this.portrait,
  }) : super(key: key);


  Widget build(BuildContext context) {
    return LayoutBuilder(
      builder: (context, boxConstraints) {
        var orientation = MediaQuery.of(context).orientation;
        if (orientation == Orientation.landscape) {
          if (landscape != null) {
            return landscape(context);
          }
        }

        return portrait(context);
      },
    );
  }
}

We use a LayoutBuilder to always get a Fresh Context from the created element and then execute our builders for landscape and portrait to get and return the resulting widget. Not a major difference but it does remove the state error that gave me a red screen. Next up is the big update. Open up the drawer_option_mobile.dart file and remove all the constructor and property code at the top. Then instead of extending from the StatelessWidget we will extend from the BaseModelWidget with a type DrawerItemData. Then we'll receive our model that we provided through Provider.value in the build function!

class DrawerOptionMobilePortrait extends BaseModelWidget<DrawerItemData> {

  Widget build(BuildContext context, DrawerItemData data) {
    return Container(
      padding: const EdgeInsets.only(left: 25),
      height: 80,
      child: Row(
        children: <Widget>[
          Icon(
            data.iconData,
            size: 25,
          ),
          SizedBox(
            width: 25,
          ),
          Text(
            data.title,
            style: TextStyle(fontSize: 21),
          )
        ],
      ),
    );
  }
}

You can do the same for the landscape widget.

class DrawerOptionMobileLandscape extends BaseModelWidget<DrawerItemData> {

  Widget build(BuildContext context, DrawerItemData data) {
    return Container(
      height: 70,
      alignment: Alignment.center,
      child: Icon(data.iconData),
    );
  }
}

And the tablet widget as well.

class DrawerOptionTabletPortrait extends BaseModelWidget<DrawerItemData> {

  Widget build(BuildContext context, DrawerItemData data) {
    return Container(
      width: 152,
      alignment: Alignment.center,
      child: Column(
        mainAxisSize: MainAxisSize.min,
        children: <Widget>[
          Icon(
            data.iconData,
            size: 45,
          ),
          Text(data.title, style: TextStyle(fontSize: 20)),
        ],
      ),
    );
  }
}

That's basically the update for passing down data through provider, easily to all of the widgets that requires it. Having it in the build function itself takes away the amount of boilerplate required although with any architecture, we always have some. That makes it predictable and easy to follow down the line.

Next up let's go over how we'll bind a view to a viewmodel through using a ChangeNotifier. We'll start by creating a simple ViewModel for the home view that will display a string that we'll update, just to show the binding working. If you want an in depth architecture guide you can look at this tutorial. Create a new folder called viewmodels and inside a new file called home_viewmodel.dart

class HomeViewModel extends ChangeNotifier {
  String title = 'default';

  void initialise() {
    title = 'initialised';
    notifyListeners();
  }

  int counter = 0;
  void updateTitle() {
    counter++;
    title = '$counter';
    notifyListeners();
  }
}

I know, very basic, but the point is to show that it works the same as my usual architecture, so the ins and outs of that can be picked up from that video series. Then we can go do some familiar work over in home_view.dart. We'll surround the ScreenTypeLayout with a BaseWidget of type HomeViewModel and return the current widget UI to the builder. For the viewModel property we will pass in a new instance of the HomeViewModel, and onModelReady we will call model.initialise.

 class HomeView extends StatelessWidget {

  Widget build(BuildContext context) {
    return BaseWidget<HomeViewModel>(
      viewModel: HomeViewModel(),
      onModelReady: (model) => model.initialise(),
      builder: (context) => ScreenTypeLayout(
        mobile: OrientationLayout(
          portrait: (context) => HomeMobilePortrait(),
          landscape: (context) => HomeMobileLandscape(),
        ),
        tablet: HomeViewTablet(),
      ),
    );
  }
}

And last but definitely not least we will make use of our BaseModelWidget to get our model through the build function. I'll only update the HomeMobilePortrait file under home_view_mobile.dart and you can do the other three widgets. We also add a floating action button that calls the updateTitle function on the model to show that it's still reactive and bound to those values.

class HomeMobilePortrait extends BaseModelWidget<HomeViewModel> {
  final GlobalKey<ScaffoldState> _scaffoldKey = GlobalKey<ScaffoldState>();


  Widget build(BuildContext context, HomeViewModel model) {
    return Scaffold(
      key: _scaffoldKey,
      drawer: AppDrawer(),
      floatingActionButton: FloatingActionButton(
        onPressed: () {
          model.updateTitle();
        },
      ),
      body: Column(
        crossAxisAlignment: CrossAxisAlignment.start,
        children: <Widget>[
          Padding(
            padding: const EdgeInsets.all(16),
            child: IconButton(
              icon: Icon(Icons.menu, size: 30),
              onPressed: () {
                _scaffoldKey?.currentState?.openDrawer();
              },
            ),
          ),
          Expanded(
            child: Center(
              child: Text(model.title),
            ),
          )
        ],
      ),
    );
  }
}

That's the end of my responsive UI series. This will be the architecture that I'll be using for a potential client that wants a multi platform system to run on Mobile, Tablet and Web and potentially Desktop in the future. I've really enjoyed setting this up. You can find the final code here.

Thank you for reading, this was a fun series of problems to solve for a production and scalable solution. Please leave any feedback, I'd love to hear what you think about it or ways to improve it.
